Seeburg 100 Selection Jukeboxes of the 1960’s & Early 1970’s

Seeburg repair manual for 100 play models from the 60’s and 70’s. Operation and Trouble Shooting Guide by Anthony Miller 112 pages


Part Number (SKU):    72-6623 Categories ,

In stock

This book covers all of the 100-selection machines built between 1964 and 1975. The first of these, the U100, was the industry’s first all solid-state machine. This book covers that machine, the Discotheque, Junior version of it, and all the later electromechanical Selector and Pricing Unit 100 selection machines, explaining how everything works, including the amplifiers and optional Steppers. Contains schematic diagrams of the Pricing Units, Control Centers, Steppers, and Amplifiers used in these machines, except the SHP2 (introduced in the SB100 Magnastar), covered in ‘The Seeburg SHP Amplifiers’, see below. Chapters include: Introduction, Schematic Symbols, The Pricing Unit, The Selection System, The Stepper, Motor and Mechanism Power, Sound System, Troubleshooting, and Semiconductor Cross-Reference. The Troubleshooting and Semiconductor Cross-References are worth the price of the book alone!
